CFM2-2K+4K-DP

2+4KW Constant Impedance FM Combiner (Double Cavity)

Features

Mechanical characteristics

  • Input narrowband EIA 7/8"
  • ınput broadband EIA 7/8"
  • Output eıa 7/8"
  • Overall dimensions [WxDxH] [mm.] 456x421x1022
  • Weight [kg.] 55
  • Temperature range [° C] -10 ÷ +50


Electrical characteristics

  • Frequency range [MHz] 87.5 ÷ 108
  • N.B İnsertion Loss [dB] < 0.5
  • B.B İnsertion Loss [dB] <0.2
  • Min. distance between channels [MHz] 1.4
  • Insulation NB>BB [dB] > 40
  • Insulation BB>NB [dB] >40
  • Return loss by channels [dB]>26
  • Input/Output impedance [Ohm] 50
  • Narrowband maximum power[W] 2000
  • Maximum Output Power [W] 6000
