2.5 kW FM Transmitter, Mains efficiency (> 67%), Power Consumption 3800VA
Digital exciter, Remote Control via Internet, High efficiency (Less energy consumption, Less heating), Extra power supply for control system, Broadb |
|
 |
 |
 |
 |
Digital Studio-Transmitter Link
Complete solution for 10-12 GHz Band TV and FM Radio Link requirements.
Composed of: Encoder, Decoder, Antennas, Cables and connectors
There are 1 Video and 2 Audio Inputs/outputs |
|
|
|
|
 |
BROADCAST CONSOLE
Verry compact radio console including 6+6=12 Inputs(5 microphones, 1 phono, 6 lines), 2 Telephone hybrids, Control room, Studio return, Onair lamp switch |
|
|
|
|
 |
RDS ENCODER
Satellite Programmable(sending different messages to different transmitters via uplink)
50 lines for PSN, 10 different pages, including Song&Singer Name broadcasting software |
|
|
|
|
 |
PROFESSIONAL FM/AM MONITORING RECEIVER
DEVOTION is a completely software defined radio that can be monitor the FM radio stations in 87.5-108MHz frequency band.
It has 1.5W speakers, headphones jack and audio outputs to |
|
|
|
|
 |
800W RF Pallet Amplifier
Pout:800W Gain(dB):25dB Vdc:46V
Transistor:BLF578 |
|
|
|
|
|
| We launched FM Monitoring Receivers and introduced FM transmitters, DVB-T2 Audio/Video Microwave Links in Amsterdam IBC 2012, 7-11 September 2012, the world's largest trade fair. |
15.09.2012 |
|
 |
There are two kinds of FM Monitoring Receivers which analyzing the quality of the FM radio broadcasting and visualize RDS information, if the receiving signal level decreases, the equipment runs siren to warn the user. DEVOTION has 1U rack box with 2W stereo speakers. COMPANION has 20W speaker with a table-type wooden box. It has AUX and USB ports. Both have excellent sound quality because of its software based demodulation. LCD shows temperature, hummidity and time when switches off.
IBC 2012, hundreds of visitors are fascinated especially designing of the FM transmitters. FM transmitters that we produce till 20KW, have LDMOS pallet amplifier modules with BLF578, now it is used by manymanufacturers in the world and after this fair will be used more.
ONAIR started to use SMD pick and place machine in first quarter of 2012, all the modules are produced in our assembling plant, tested by the latest test&measuring equipment and experienced engineers&technicians.
|
|
 |
 |
| We participated to the Singapore Broadcast Asia Exhibition between 19-22 June 2012. |
12.07.2012 |
|
|
We presented our DVB-T2 transmitters, FM transmitters, video/audio microwave links, pallet amplifiers and warning FM receiver.
FM&TV transmitters have remote control via internet(TCP/IP), N+1 redundancy system, humidity and temperature sensors inside. There is a relay output switching aircondition when humidity is high. With these specifications, the transmitter sites don’t need any remote control&protection systems if the transmitters are ONAIR brand.
All the transistors used inside the FM&TV transmitters are LDMOS. So, the efficiencies are the highest as possible as with the latest technology.
So, the customers of ONAIR are using the energy efficiently, pay less energy receipts and don’t invest for a remote control system for the transmitters. They also manage their transmitter networks from their computers, they receive event logs via email/SMS when any alarm occurs in the transmitters.
When the customer compared these specifications and the price with other brands, ONAIR transmitters are “MUST BUY”. |
|
|
|
| We presented LDMOS FM transmitters and DVB-T/T2 transmitters at NAB SHOW Las Vegas-USA |
21.04.2012 |
|
|
NAB SHOW is the most important exhibition for North and Latin American market. ONAIR has targeted to reach to the manufacturers in this market at NAB SHOW. We demonstrated our pallet amplifiers with the new LDMOS devices from NXP and Freescale, and also the amplifier&transmitters contains these new pallet amplifiers. There was really great interest! |
|
|
|
| ONAIR presented low power UHF transmitters and amplifiers designed for the digital market (DVB-T/H, ATSC, ISDB-T, DMB-T/H) at CABSAT 2012 Exhibition in Dubai. |
04.04.2012 |
|
|
These transmitters and amplifiers have been designed for better quality , reliability and performances than the previous generation used Mosfet transistors. All characteristics are improved and the cost reduced using the latest generation LDMOS transistors and ARM microcontroller. |
|
|
|
| ONAIR products had great interest at IBC 2011. |
15.09.2011 |
|
|
ONAIR, FT Series FM Transmitters and DVL series Digital Microwave Links designed with latest technology had great interest at IBC 2011 held on 9-13 September at Amsterdam. |
|
|
|
|
